Overview

The TOXU TX-C069 is a Mini FAKRA Z Female to FAKRA A Code Male RF Cable Assembly developed for reliable RF signal transmission in automotive antenna systems, telematics devices and wireless communication equipment.

This cable assembly combines a Mini FAKRA Z Female connector with a standard FAKRA A Code Male connector, providing an efficient interface conversion solution while maintaining stable RF performance.

Supporting a characteristic impedance of 50Ω and operating frequencies up to 6GHz, the TX-C069 is suitable for various automotive RF and GNSS applications.

Key Features

Mini FAKRA to FAKRA Interface

Connects Mini FAKRA and standard FAKRA interfaces for reliable RF signal transmission in automotive electronic systems.

Stable 50Ω RF Performance

Designed with a 50Ω characteristic impedance to support dependable RF signal transmission.

Multiple Cable Options

Available with RG316, RG58, LMR200, LMR240 and LMR400 coaxial cables according to customer requirements.

Wide Frequency Capability

Supports RF applications operating from DC to 6GHz.

Customized Cable Assembly

Supports customized cable lengths, connector combinations and complete RF cable assembly solutions.

OEM Manufacturing Support

Prototype development, engineering validation and mass production are supported for OEM and ODM projects.

Technical Specifications

Applications

The TX-C069 RF Cable Assembly is suitable for:

● Automotive antenna systems

● GNSS positioning equipment

● Vehicle telematics systems

● Automotive infotainment systems

● RF communication equipment

● Wireless electronic devices

System Integration

TOXU RF cable assemblies provide reliable RF interconnection between automotive antennas and communication modules.

Typical integration structure:

Automotive Antenna

↓

Mini FAKRA to FAKRA RF Cable Assembly

↓

GNSS / Telematics Module

↓

Electronic Control Unit (ECU)

Complete RF Hardware Solution Support

RF Cable Assembly Solutions

TOXU provides customized RF cable assemblies with different connector combinations, cable structures and cable lengths for automotive and communication applications.

RF Connector Solutions

We support Mini FAKRA, FAKRA, SMA, SMB, MMCX, MCX, TNC, BNC and other RF connector solutions.

Antenna Integration

TOXU supports complete integration between antennas, RF cable assemblies and connector systems to simplify customer hardware development.

Hardware Customization

From prototype samples to volume production, TOXU provides flexible OEM and ODM manufacturing services.

Why Choose TOXU

TOXU is an RF hardware integration solution provider specializing in RF cable assemblies, RF connectors, GNSS antennas and customized RF products.

Our engineering team supports customers from prototype verification to mass production with reliable manufacturing capability and consistent product quality.

FAQ

Q1: Can TOXU customize RF cable assemblies?

Yes. We support customized connector combinations, cable types, cable lengths and OEM manufacturing services.

Q2: Which connector combinations are available?

We support Mini FAKRA, FAKRA, SMA, SMB, MMCX, MCX, TNC, BNC and other customized RF connector combinations.

Q3: Can TOXU support OEM and ODM projects?

Yes. Prototype development, engineering validation and volume production are all supported.

Q4: What products can TOXU provide besides RF cable assemblies?

TOXU also provides RF connectors, GNSS antennas, communication antennas and complete RF hardware integration solutions.
