Overview

The TOXU TX-ZED-F9P-04B-MB RTK GNSS Receiver Module Board is based on the u-blox ZED-F9P-04B multi-band GNSS chipset, designed for high-performance positioning applications requiring reliable RTK capability.

The u-blox ZED-F9P-04B supports simultaneous reception of multiple satellite constellations including GPS, GLONASS, Galileo, BeiDou and QZSS, providing stable satellite tracking and positioning performance.

With dual-band L1/L2 GNSS capability and support for RTK correction services such as NTRIP and base station corrections, this receiver board is suitable for UAV navigation, robotics, surveying equipment and precision positioning systems.

Key Features

u-blox ZED-F9P-04B Integration

Integrated with the u-blox ZED-F9P-04B GNSS chipset for high-performance RTK positioning applications.

Dual Band L1/L2 GNSS Support

Supports dual-frequency GNSS signals to improve positioning stability and signal availability.

Multi-Constellation GNSS

Supports GPS, GLONASS, Galileo, BeiDou and QZSS satellite navigation systems.

RTK Positioning Support

Supports RTK positioning with correction data from NTRIP or base station systems.

Multiple Communication Interfaces

Provides UART, USB and I2C interfaces for flexible integration with embedded platforms.

Compact Development Board Design

Compact PCB design enables easy integration into UAV, robotics and autonomous navigation systems.

Technical Specifications

Hardware Interface

The TX-ZED-F9P-04B-MB provides flexible hardware interfaces for integration into navigation and embedded systems.

• SMA GNSS Antenna Connector

• USB Interface

• UART Interface

• I2C Interface

Applications

• UAV Navigation Systems

• Robotics Platforms

• Surveying Equipment

• Autonomous Vehicles

• Precision Agriculture Systems

System Integration

The TX-ZED-F9P-04B-MB can be integrated with flight controllers, embedded computers and autonomous systems through standard communication interfaces.

GNSS Antenna → u-blox ZED-F9P-04B RTK GNSS Board → Controller / Computer → Navigation System

Why Choose TOXU

• GNSS hardware development and integration capability

• RF antenna and positioning solution experience

• IATF16949 & ISO9001 certified manufacturing

• OEM/ODM customization support

• Prototype development to mass production

FAQ

Q1: What GNSS chipset is used in this board?

A1: The board integrates the u-blox ZED-F9P-04B GNSS chipset.

Q2: Does this board support RTK positioning?

A2: Yes, it supports RTK positioning with NTRIP or base station correction data.

Q3: Which GNSS systems are supported?

A3: It supports GPS, GLONASS, Galileo, BeiDou and QZSS.

Q4: What applications are suitable for this receiver board?

A4: It is suitable for UAVs, robotics, surveying equipment and precision agriculture systems.
