Overview

The TOXU TX-MX5-RTK01 RTK GNSS Receiver Board is based on the Septentrio Mosaic-X5 multi-frequency GNSS chipset, designed for applications requiring reliable and high-performance positioning capability.

The Septentrio Mosaic-X5 supports triple-band GNSS signals including L1, L2 and L5, with concurrent tracking of multiple satellite constellations including GPS, GLONASS, Galileo and BeiDou.

With RTK positioning capability, USB and UART communication interfaces, and compact development board design, the TX-MX5-RTK01 is suitable for UAV navigation, robotics, precision agriculture, surveying equipment and autonomous systems.

Key Features

Septentrio Mosaic-X5 Integration

Integrated with the Septentrio Mosaic-X5 GNSS chipset to provide advanced multi-frequency positioning performance.

Triple Band GNSS Support

Supports L1/L2/L5 GNSS frequency bands for enhanced satellite tracking capability.

Multi-Constellation GNSS Reception

Supports GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC and SBAS satellite systems.

RTK Positioning Capability

Supports RTK and GNSS positioning modes with centimeter-level positioning performance.

High Update Rate

Supports update rates up to 100 Hz for dynamic positioning applications.

Embedded Integration Design

Provides USB, UART and XBee expansion interfaces for integration with UAV controllers and embedded systems.

Technical Specifications

Hardware Interface

The TX-MX5-RTK01 provides multiple hardware interfaces for flexible integration into navigation and autonomous systems.

• USB Interface

• UART Interface

• XBee Expansion Interface

• GNSS Antenna Connector

Applications

• UAV Navigation Systems

• Robotics Platforms

• Surveying Equipment

• Precision Agriculture Systems

• Autonomous Navigation Systems

System Integration

The TX-MX5-RTK01 can be integrated with UAV flight controllers, embedded computers and autonomous platforms through standard communication interfaces.

GNSS Antenna → Septentrio Mosaic-X5 RTK GNSS Board → Controller / Computer → Navigation System

Why Choose TOXU

• GNSS hardware development and integration capability

• RF antenna and positioning solution experience

• IATF16949 & ISO9001 certified manufacturing

• OEM/ODM customization support

• Prototype development to mass production

FAQ

Q1: What GNSS chipset is used in this receiver board?

A1: The TX-MX5-RTK01 integrates the Septentrio Mosaic-X5 GNSS chipset.

Q2: Which GNSS bands are supported?

A2: It supports triple-band GNSS signals including L1, L2 and L5.

Q3: Does this board support RTK positioning?

A3: Yes, it supports RTK positioning with centimeter-level accuracy.

Q4: What applications can use this GNSS board?

A4: It is suitable for UAVs, robotics, surveying equipment and precision agriculture systems.
