Overview

The TOXU TX-ZED-F9P-04B RTK GNSS Receiver Board is a high precision positioning solution based on the u-blox ZED-F9P-04B multi-band GNSS module.

The board integrates multi-frequency GNSS reception and RTK technology to provide centimeter-level positioning performance with fast convergence time and reliable navigation capability.

Supporting GPS, GLONASS, Galileo, BeiDou and QZSS satellite constellations, the TX-ZED-F9P-04B is suitable for UAV navigation, robotics, autonomous systems, precision agriculture and industrial positioning applications.

Key Features

u-blox ZED-F9P-04B Integration

Integrated with the u-blox ZED-F9P-04B GNSS module for professional RTK positioning applications.

Multi-Band GNSS Support

Supports multiple GNSS frequency bands including B1I, B2I, E1B/C, E5b, L1C/A, L1OF and L2C/L2OF for reliable positioning.

Centimeter-Level RTK Capability

Supports RTK rover operation and standard RTCM correction input for centimeter-level navigation applications.

Multi-Constellation Reception

Concurrent reception of GPS, GLONASS, Galileo, BeiDou and QZSS satellite systems improves positioning availability.

Multiple Communication Interfaces

Supports UART × 2, USB, SPI and I2C interfaces for flexible system integration.

Advanced GNSS Functions

Supports jamming detection, data logging, secure boot, time pulse output and active antenna control functions.

Technical Specifications

Hardware Interface

The TX-ZED-F9P-04B GNSS receiver board provides flexible interfaces for embedded positioning system integration.

• SMA antenna connector for external active GNSS antenna

• UART × 2 communication interface

• USB interface

• SPI interface

• I2C interface

• RTCM correction data support

Applications

• UAV Navigation Systems

• Robotics Platforms

• Autonomous Vehicles

• Precision Agriculture Equipment

• Surveying and Mapping Systems

• Industrial Automation Equipment

System Integration

The TX-ZED-F9P-04B GNSS receiver board can be integrated with flight controllers, embedded computers, industrial controllers and autonomous navigation systems through standard communication interfaces.

GNSS Antenna → RTK GNSS Receiver Board → MCU / Controller → Navigation System

Why Choose TOXU

• GNSS positioning hardware development capability

• RF antenna and GNSS solution integration experience

• IATF16949 & ISO9001 certified manufacturing

• OEM/ODM customization support

• Prototype development to mass production

FAQ

Q1: What GNSS module is used on this board?

A1: The board integrates the u-blox ZED-F9P-04B high precision GNSS module.

Q2: Does this board support RTK positioning?

A2: Yes, it supports RTK rover operation with RTCM correction data.

Q3: Which satellite systems are supported?

A3: It supports GPS, GLONASS, Galileo, BeiDou and QZSS.

Q4: Can TOXU provide GNSS customization?

A4: Yes, TOXU provides GNSS hardware customization and positioning solution integration support.
