Overview

The TOXU TX-CN-BNC-001 is a BNC male cable mount RF coaxial connector designed for RF cable assembly applications. It provides a reliable connection interface for coaxial cables including RG316, RG174 and similar cable types.

The connector adopts a BNC bayonet locking structure, allowing fast connection and disconnection while maintaining stable RF signal transmission performance.

With 50Ω impedance design and compact cable termination structure, the TX-CN-BNC-001 is suitable for communication equipment, RF devices, antenna systems and test equipment.

TOXU provides RF connector solutions together with RF cable assembly and antenna integration services to support customized RF hardware projects from prototype development to mass production.

Key Features

BNC Male Connector Interface

Designed with standard BNC male interface for quick-lock RF coaxial connection.

Cable Mount Structure

Designed for coaxial cable assembly applications with RG316, RG174 and similar RF cables.

50Ω Impedance Design

Suitable for standard 50Ω RF systems requiring stable signal transmission.

Wide Frequency Capability

Supports DC to 4GHz frequency range for various RF applications.

Reliable Mechanical Connection

The bayonet coupling structure provides convenient installation and secure connection.

Technical Specifications

Applications

The TX-CN-BNC-001 BNC RF coaxial connector is suitable for:

• RF Cable Assemblies

• Wireless Communication Equipment

• Antenna Systems

• RF Test Equipment

• Electronic Communication Devices

System Integration

The BNC connector can be integrated into RF hardware systems:

Antenna System

↓

RF Cable Assembly

↓

BNC Connector

↓

Communication Equipment / RF Module

TOXU supports connector matching, RF cable assembly development and antenna integration solutions for customized RF hardware applications.

Complete RF Hardware Solution Support

RF Connector Solutions

TOXU provides RF connector solutions including SMA, MMCX, BNC, TNC, N-Type, FAKRA, Mini FAKRA and customized RF connectors for different applications.

RF Cable Assembly

TOXU provides customized RF cable assemblies with connector matching, cable selection and assembly support.

Antenna Integration

TOXU supports RF interface integration between antennas, cables and connector systems.

Hardware Customization

TOXU supports prototype development, engineering validation and mass production for customized RF hardware projects.

Why Choose TOXU

TOXU provides integrated RF hardware solutions covering connectors, RF cable assemblies, antennas and customized hardware development.

With RF engineering capability and manufacturing support, TOXU helps customers complete projects from prototype validation to mass production.
