Based on the ultra-robust M9 platform, UBX-M9340 is the first u-blox chip to include both UDR and ADR options integrated into one receiver. The chip is designed to support various aftermarket telematics applications. It includes different dynamic models for cars, motorcycles, and micromobility applications. Furthermore, the whole solution runs on the chip, which means that it is not necessary to run external libraries on the host.

This innovative u-blox M9 standard precision GNSS chip with dead reckoning technology delivers three times better accuracy than GNSS-only receivers, enabling a smooth urban navigation or tracking experience. In challenging environments, GNSS-only receivers typically have many outliers. In such conditions, statistical accuracy can easily exceed 10 meters. With UBX-M9340, there are few or no outliers. In typical urban scenarios, UBX-M9340 offers sub- 5-meter accuracy.

Maximum position availability is guaranteed, thanks to the concurrent reception of four global navigation satellite systems (GPS, Galileo, GLONASS, and BeiDou) and dead reckoning technology.

UDR enables fast time to market, and ADR improves the accuracy performance if there are long GNSS outages. UBX-M9340 is pin-compatible with other u-blox M9 chips such as UBX-M9140, offering the possibility to easily populate the same boards with different product versions.

u-blox M9 GNSS chips are qualified according to AEC-Q100 and are manufactured in ISO/TS 16949 certified sites.
