Features

•Support GPS/BD2

•Support EASYTM self-generated orbit prediction

•Support EPOTM orbit prediction

•Support SBAS ranging (WAAS, EGNOS, GAGAN,MSAS)

•Support DGPS (RTCM)

•Support Jamming Removing

•Low-noise amplifier has been integrated

Interfaces

•Serial interfaces UART, SPI / I²C

•Digital I/O EINT0 input

Pulse-per-second (PPS)

•Protocols NMEA

PMTK

PSIM

Support product

•SIM68 EVB KIT with USB V2.0 full speed interface

Performance data

•Receiver type

33tracking/99 acquisitionchannel GNSS receiver

•Max. update rate 10Hz

•Sensitivity1

Tracking:167 dBm

Reacquisition:-160 dBm

Cold starts:-148 dBm

•Time-To-First-Fix2

Cold starts:28 s

Warm start:26 s

Hot starts:<1s

EPO Assist:13s（CTTFF)

• Accuracy

Automatic Position3:<2.5m CEP

Speed4:0.1m/s

•Operation temperature5: -40℃~+85 ℃

Electrical data

•Power supply: 2.8V~4.3V

•Backup power: 2.3V~4.6V

•Power consumption2,6

Acquisition: 34mA

Tracking: 30mA

AlwaysLocateTM: 340uA

Backup: 14uA

•Antenna type Active and passive

•Antenna power External or internal VCC_RF

Approvals

• RoHS\REACH
